Automatic EVA Raincoat Making Machine | Complete Cardigan Raincoat Production Line
- Home
- Automatic EVA Raincoat Making Machine | Complete Cardigan Raincoat Production Line
Products Details
Automatic Eva Raincoat Making Machine supports the documented configuration and application requirements.
Machine Running Video | Full Set EVA Cardigan Raincoat Production Equipment
Complete EVA Cardigan Raincoat Production Line
EVA raincoat making machine production line configured for adult and children’s cardigan-style rainwear. Also searched as an automatic raincoat making machine, disposable raincoat production line, plastic raincoat making machine or rainwear manufacturing line, this complete solution combines five equipment types for body forming, sleeve forming, manual assembly sealing, hood-cord welding and roll-material reversing and flattening.
Complete Line Configuration
- Automatic EVA cardigan raincoat body making machine – 1 set
- EVA raincoat sleeve making machine – 1 set
- Pneumatic heat sealing machine – recommended quantity: 12-15 units
- Pneumatic hood cord sealing machine – recommended quantity: 3-4 units
- Raincoat roll-material reversing and flattening machine – 1 set
The quotation price table lists one set for each equipment item. The higher quantities shown for the pneumatic heat sealers and hood cord machines are the separate recommended production arrangement stated in the source document.
1. Automatic EVA Raincoat Body Making Machine
The automatic EVA raincoat body making machine forms the main body section for adult and children’s cardigan raincoats. Related names include EVA raincoat body machine, plastic raincoat body making machine and disposable raincoat body forming machine. The quoted machine is available with a heating or ultrasonic process option.
| Parameter | Specification |
|---|---|
| Production speed | 10-15 pcs/min |
| Total / operating power | 10 kW / 6-8 kW |
| Voltage | 380 V, 50 Hz |
| Material width | 1,500 mm |
| Machine dimensions | 6.7 x 2.2 x 1.6 m |
| Gross weight | 4,000 kg |
| Packaging | 2,224 x 2,320 x 1,600 mm = 8.31 m3; 2,224 x 2,100 x 2,100 mm = 9.87 m3; 2,224 x 2,600 x 1,800 mm = 10.48 m3 |
Main Components
- Inovance PLC, 10-inch HMI and eight servo motors with motion control
- OMRON sensors and photoelectric detection
- Airtac pneumatic components and solenoid valves
- Constant-tension control and web-correction unit
- Two imported-steel DC53 punching dies and four copper-knife edge dies
- CHINT electrical switches and low-voltage components
- HRB linear bearings and bearings
2. EVA Raincoat Sleeve Making Machine
The EVA raincoat sleeve making machine produces sleeve sections for adult and children’s raincoats. Search variants include raincoat sleeve machine, EVA sleeve forming machine, raincoat arm sleeve making machine and ultrasonic raincoat sleeve machine.
| Parameter | Specification |
|---|---|
| Production speed | 20-40 pcs/min |
| Total / operating power | 5 kW / 3-4 kW |
| Voltage | 220 V, 50 Hz |
| Small opening size | ≥400 mm, as stated |
| Sleeve length / width | ≤580 mm / ≤580 mm |
| Elastic folded section | 3 ± 1 mm |
| Machine dimensions | 2 x 1.2 x 1.4 m |
| Gross weight | 1,500 kg |
Main equipment includes a 55 mm Hengxiang round ultrasonic unit, arc-forming die, trimming knife, OMRON photoelectric detection, Airtac pneumatic components, manual tension adjustment and an upper-strap tension-adjustment device.
3. Pneumatic Heat Sealing Machine
The pneumatic heat sealing machine is used for manual forming and sealing and for joining formed parts to the raincoat body. It is also called a raincoat heat sealing machine, EVA film sealing machine, pneumatic film sealer or raincoat seam sealing machine. Two heating wires are provided: one for edge sealing and one for cutting.
| Parameter | Specification |
|---|---|
| Suitable materials | EVA and PE |
| Sealing length | 900 mm |
| Voltage | 220 V, 50 Hz |
| Machine dimensions | 1,100 x 500 x 1,060 mm; worktable height 730 mm |
| Recommended quantity | 12-15 units |
4. Pneumatic Hood Cord Sealing Machine
The pneumatic hood cord sealing machine welds and seals hood-cord sections for EVA and PE raincoats and various disposable protective garments, with an edge-folding assistance function. Buyer terms include raincoat hood cord welding machine, hood string sealing machine, raincoat cap sealing machine and EVA raincoat hood welding machine.
| Parameter | Specification |
|---|---|
| Power supply | 220 V, 50 Hz |
| Sealing width / length | 2 mm / 900 mm |
| Impulse power | 1,500 W |
| Sealing time | 0-9.99 s, adjustable |
| Auxiliary function | Water-cooling device |
| Operating air pressure | 0.4-0.6 MPa |
| Weight | 30 kg |
| Machine dimensions | 1,200 x 550 x 800 mm |
| Recommended quantity | 3-4 units |
5. Raincoat Roll-Material Reversing and Flattening Machine
This roll-material reversing and flattening machine turns material through 360 degrees, arranges the face and reverse direction, and flattens the material for subsequent processing. It is also searched as a fabric reversing machine, roll material turning machine, film web reversing machine or raincoat fabric flattening machine.
| Parameter | Specification |
|---|---|
| Power supply | 220 V, 50 Hz |
| Raw-material width | 1.6 m |
| Reversing speed | Adjustable |
| Counting function | Digital display |
| Weight | 200 kg |
| Machine dimensions | 2,655 x 900 x 1,900 mm |
Configuration Information Required
Provide the intended adult or children’s raincoat size, raw-material specification, preferred heating or ultrasonic process, target production arrangement, factory voltage and available installation space. Requirements outside the quoted configuration should be reviewed before order confirmation.
Commercial Terms and After-Sales Service
- Payment: 40% deposit; balance after acceptance and before delivery
- Price term: EXW, excluding tax and freight
- Delivery: within 30 working days after receipt of the deposit
- Packing: stretch-film wrapping
- Warranty: one year for quality issues attributable to the supplied machinery; improper-operation damage is excluded
- Lifetime after-sales service is available
